The Winterhalter C50 Single Rinse Rack Conveyor Dishwasher with Dryer is ideal for commercial establishments such as restaurants, hotels, and catering services that require efficient and hygienic dishwashing in a compact space. Its modular design allows for customization to meet specific operational needs, and its high throughput ensures that large volumes of dishes can be cleaned quickly and effectively.
Key Features
- High Throughput: Capable of washing up to 260 racks per hour, making it ideal for high-volume operations.
- Modular Design: Offers flexibility with options to add pre-cleaning zones, drying zones, and corner conveyors as needed.
- Energy Efficiency: Zone activation ensures that only the necessary sections operate, conserving water, energy, and chemicals.
- User-Friendly Operation: Intuitive controls with automatic programs for cleaning support, quick emptying, and filling.
- Hygienic Design: Deep-drawn tank base and double-skinned doors reduce limescale deposits and simplify cleaning.
- HighTemp Option: Optional kit increases tank heating power to 27 kW, raising tank water temperature to 73°C for enhanced hygiene.
| Feature | Details |
|---|---|
| Model | Winterhalter C50 SM-M |
| Dimensions (L x W x H) | 2,500 x 800 x 1,850 mm |
| Rack Dimensions | 500 x 500 mm |
| Clear Entry Height | 450 mm |
| Tank Capacity | 95 liters |
| Tank Heating Power | 18 kW (upgradeable to 27 kW with HighTemp kit) |
| Rinse Water Temperature | 85°C |
| Wash Pump Power | 1.6 kW |
| Noise Emission | <70 dB(A) |
| Power Consumption | 49.7 – 58.6 kW |
| Electrical Connection | 380–415V / 3N~ / 50Hz |
| Weight (Net / Gross) | 291 kg / 405 kg |
| Performance | Up to 260 racks per hour |
| Water Pressure Requirement | 1.5 – 6.0 bar (150 – 600 kPa) |
| Max. Inlet Water Temp. | 60°C |
| Construction | Stainless steel with double-skinned hygiene doors |
| Filtration System | Double filtration with pump inlet filter and flat strainer |
| Operating Interface | Language-neutral, color-coded display with self-explanatory pictograms |
